TIE ROD END | JIKIU - ET23481L
Specification
Mounting Length (mm):
86
Thread (in/out)
M16x1.5 LHT
Cone Size Ø(mm) :
12.5
Thread (Cone out)
M12x1.25
Cone Pitch:
1:8
Mounting Height (mm):
31
Full Lenght (mm):
107
Overall Height (mm):
65
Location
Steering system
Position
Left
Crosses
Owner
Number
555 SANKEI
SE-7481L
A.B.S.
230453
Blue Print
ADK88724
CTR
CE0629L
CTR
CE0945
CTR
CES-27
CTR
CES-6L
Febi
33533
LYNXauto
C4232L
Meyle
33-16 020 0021
Owner
Number
Sidem
77236
SUZUKI
48820-80000
SUZUKI
48820-80001
SUZUKI
48820-80002
SUZUKI
48820-81A00
SUZUKI
48820-81A01
TEKNOROT
SZ-252
ZEKKERT
SN-2327
